GCRを業務で扱うことになったのでやってみる。
GCRってのはgoogle container registoryっていうdocker image置き場。
自分のプロジェクトの中でのみ公開したいときに使うみたい。
ビルドはローカルPCのdockerでやってイメージ作ってから、GCRへ認証を通しておいてdocker push
することでイメージ作れる。
GCRに作ったイメージはGKEのポッドに展開して動かせる。
GCR(google container registory)はGAR(google artifact registory)に移ってくのかも?
まぁええ。やってみよ。
参考にさせてもらったページは、先にcloud source repositoriesへ登録してるところもあったから、ついでにやってみた。
普段使ってるGCPのプロジェクトとは別枠でやってみた。
仮想マシン作成
マーケットプレースから流用して仮想マシン作る。
vcpuとメモリは予算に応じて。自分は4コア16GBメモリHDD50GBで作った。
無料枠やからこれぐらいでええ。ディスクを多くとったのは後でdocker入れたいから。
ファイアウォールで80と443のポート開けとく設定も入れとく。
起動してコマンドライン使えるまで1分。
めちゃ楽。
aptしてgit入れる
rootユーザになって以下を動かす。
apt autoremove apt clean apt update apt upgrade
保留のパッケージが残ることもあるけど、更新対象がなくなるまで動かす。
全部で2回動かせばいい。
途中で確認メッセージが出ることあるけど、全部「承認」とか「OK」でええ。
2回目のapt upgrade
までやるとこんな感じ。
root@ubuntu22:~# apt autoremove :(中略) root@ubuntu22:~# apt clean :(中略) root@ubuntu22:~# apt update :(中略) root@ubuntu22:~# apt upgrade :(中略) root@ubuntu22:~# apt autoremove :(中略) root@ubuntu22:~# apt clean :(中略) root@ubuntu22:~# apt upgrade Reading package lists... Done Building dependency tree... Done Reading state information... Done Calculating upgrade... Done The following packages have been kept back: libglib2.0-0 libglib2.0-bin libglib2.0-data 0 upgraded, 0 newly installed, 0 to remove and 3 not upgraded. root@ubuntu22:~#
後で使うのでgoogle cloud SDKが紐づいているか確認する。
gavannitsales@ubuntu22:~$ gcloud config list [core] account = 225919338029-compute@developer.gserviceaccount.com disable_usage_reporting = True project = fourth-elixir-383118 Your active configuration is: [default] gavannitsales@ubuntu22:~$
普通にgit入れる。
root@ubuntu22:~# apt install git Reading package lists... Done Building dependency tree... Done Reading state information... Done git is already the newest version (1:2.34.1-1ubuntu1.8). git set to manually installed. 0 upgraded, 0 newly installed, 0 to remove and 3 not upgraded. root@ubuntu22:~#
git使う初期化しとく。
git config --global user.email "sales@gavann-it.com" git config --global user.name "sales"
サンプルアプリを動かす
pythonのサンプルアプリを準備する。
参考にさせてもらったページ。
作者さんありがとう。
developmentしてくところは、たぶんcloud source repositoriesのことかな。
gcr使う前に、source repositoriesってサービスもやってみる。
cloud source repositoryはgitリポジトリで、push/pullできる。
gitからサンプルをとってくる。
gavannitsales@ubuntu22:~$ mkdir sample gavannitsales@ubuntu22:~$ cd sample gavannitsales@ubuntu22:~/sample$ git clone https://github.com/GoogleCloudPlatform/python-docs-samples.git Cloning into 'python-docs-samples'... remote: Enumerating objects: 95977, done. remote: Counting objects: 100% (1728/1728), done. remote: Compressing objects: 100% (932/932), done. remote: Total 95977 (delta 894), reused 1478 (delta 751), pack-reused 94249 Receiving objects: 100% (95977/95977), 205.77 MiB | 38.10 MiB/s, done. Resolving deltas: 100% (57057/57057), done. Updating files: 100% (4376/4376), done. gavannitsales@ubuntu22:~/sample$
gitローカルリポジトリを構成
必要な個所を抜き出してgit init
してローカルリポジトリ作る。
後で気づいたけど、requirements.txtが入ってない。
gitした元ソースのあるフォルダ近辺を見たらtutorialのフォルダがあって、そこにrequirements.txtが入ってたのでコピーして設置する必要がある。
gavannitsales@ubuntu22:~/sample$ cp -rf ./python-docs-samples/appengine/standard/flask/hello_world/ ./hello_world gavannitsales@ubuntu22:~/sample$ cd hello_world/ gavannitsales@ubuntu22:~/sample/hello_world$ git init . hint: Using 'master' as the name for the initial branch. This default branch name hint: is subject to change. To configure the initial branch name to use in all hint: of your new repositories, which will suppress this warning, call: hint: hint: git config --global init.defaultBranch <name> hint: hint: Names commonly chosen instead of 'master' are 'main', 'trunk' and hint: 'development'. The just-created branch can be renamed via this command: hint: hint: git branch -m <name> Initialized empty Git repository in /home/gavannitsales/sample/hello_world/.git/ gavannitsales@ubuntu22:~/sample/hello_world$ git add . gavannitsales@ubuntu22:~/sample/hello_world$ git commit -m "Initial Commit" [master (root-commit) 2f88308] Initial Commit 5 files changed, 98 insertions(+) create mode 100644 .gitignore create mode 100644 README.md create mode 100644 app.yaml create mode 100644 main.py create mode 100644 main_test.py gavannitsales@ubuntu22:~/sample/hello_world$
source repositoriesへpushして登録
ssh認証鍵登録が必要らしい。
gceで動いてるubuntu22のssh鍵をコピペしてssh認証鍵を登録。
2つあるうち、1つめを使った。
ssh鍵を登録したところ。
source repositoriesへpushするにはどうしたらいいか書いてある。
cloud repositoryをremoteとして追加してみる。
gavannitsales@ubuntu22:~/sample/hello_world$ git remote add google ssh://gavannitsales@gmail.com@source.developers.google.com:2022/p/fourth-elixir-383118/r/hello-world gavannitsales@ubuntu22:~/sample/hello_world$
ローカルリポジトリをcloud repositoryへ登録する。
gavannitsales@ubuntu22:~/sample/hello_world$ git push --all google Enumerating objects: 7, done. Counting objects: 100% (7/7), done. Delta compression using up to 4 threads Compressing objects: 100% (6/6), done. Writing objects: 100% (7/7), 1.55 KiB | 1.55 MiB/s, done. Total 7 (delta 2), reused 0 (delta 0), pack-reused 0 remote: Resolving deltas: 100% (2/2) To ssh://gmail.com@source.developers.google.com:2022/p/fourth-elixir-383118/r/hello-world * [new branch] master -> master gavannitsales@ubuntu22:~/sample/hello_world$
はい、入ったー。
すぐにこれはいらんけど、扱い方はイメージできた。
GCRでも似たようなことやる。
source repositoriesからpullしてとってくる
入った結果をpullしてみると、VMからはスコープ外って怒られた。
なんやねん、取れへんのかいな。
gavannitsales@ubuntu22:~$ mkdir sampleClone gavannitsales@ubuntu22:~$ cd sampleClone gavannitsales@ubuntu22:~/sampleClone$ gavannitsales@ubuntu22:~/sampleClone$ gcloud source repos clone hello-world --project=fourth-elixir-383118 ERROR: (gcloud.source.repos.clone) PERMISSION_DENIED: Request had insufficient authentication scopes. - '@type': type.googleapis.com/google.rpc.ErrorInfo domain: googleapis.com metadata: method: google.devtools.sourcerepo.v1.SourceRepo.GetRepo service: sourcerepo.googleapis.com reason: ACCESS_TOKEN_SCOPE_INSUFFICIENT If you are in a compute engine VM, it is likely that the specified scopes during VM creation are not enough to run this command. See https://cloud.google.com/compute/docs/access/service-accounts#accesscopesiam for more information about access scopes. See https://cloud.google.com/compute/docs/access/create-enable-service-accounts-for-instances#changeserviceaccountandscopes for how to update access scopes of the VM. gavannitsales@ubuntu22:~/sampleClone$
メッセージあるURLを見るとアクセススコープをgceのvmに対して変更必要らしい。
vm編集するから、OSいっかいとめなアカン。
何をつけなアカンのか調べるのじゃまくさいから、スコープ全部つけたった。
アクセススコープ変更したし、再チャレンジ!!
gavannitsales@ubuntu22:~/sampleClone$ gcloud source repos clone hello-world --project=fourth-elixir-383118 Cloning into '/home/gavannitsales/sampleClone/hello-world'... remote: Total 7 (delta 2), reused 7 (delta 2) Receiving objects: 100% (7/7), done. Resolving deltas: 100% (2/2), done. Project [fourth-elixir-383118] repository [hello-world] was cloned to [/home/gavannitsales/sampleClone/hello-world]. gavannitsales@ubuntu22:~/sampleClone$
おお、clone行けた。
diffで確認してみよか。
gavannitsales@ubuntu22:~/sampleClone$ diff -r --exclude=.git hello-world/ ../sample/hello_world/ gavannitsales@ubuntu22:~/sampleClone$
.gitのフォルダを除いて比較すると一致してますな。
pipで必要モジュール集めてサンプルアプリ起動
次にhello-worldアプリを起動してみる。
まずはpythonとpipとgunicorn入れる。
gavannitsales@ubuntu22:~/sampleClone/hello-world$ sudo apt install python-pip gunicorn Reading package lists... Done Building dependency tree... Done Reading state information... Done :(中略) update-alternatives: using /usr/bin/g++ to provide /usr/bin/c++ (c++) in auto mode Setting up build-essential (12.9ubuntu3) ... Processing triggers for man-db (2.10.2-1) ... Processing triggers for libc-bin (2.35-0ubuntu3.1) ... Scanning processes... Scanning linux images... Running kernel seems to be up-to-date. No services need to be restarted. No containers need to be restarted. No user sessions are running outdated binaries. No VM guests are running outdated hypervisor (qemu) binaries on this host. gavannitsales@ubuntu22:~/sampleClone/hello-world$
pipを更新して、requirements.txtにあるパッケージを入れてく。
gavannitsales@ubuntu22:~/sampleClone/hello-world$ pip install --upgrade pip Command 'pip' not found, but can be installed with: apt install python3-pip Please ask your administrator. gavannitsales@ubuntu22:~/sampleClone/hello-world$
ありゃ、python3入れろやぁって怒られた。
入れてからもう1回やってみるとOK。
gavannitsales@ubuntu22:~/sampleClone/hello-world$ sudo apt install python3-pip Reading package lists... Done Building dependency tree... Done Reading state information... Done :(中略) Processing triggers for man-db (2.10.2-1) ... Scanning processes... Scanning linux images... Running kernel seems to be up-to-date. No services need to be restarted. No containers need to be restarted. No user sessions are running outdated binaries. No VM guests are running outdated hypervisor (qemu) binaries on this host. gavannitsales@ubuntu22:~/sampleClone/hello-world$ pip install --upgrade pip Defaulting to user installation because normal site-packages is not writeable Requirement already satisfied: pip in /usr/lib/python3/dist-packages (22.0.2) Collecting pip Downloading pip-23.1.2-py3-none-any.whl (2.1 MB) ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 2.1/2.1 MB 13.9 MB/s eta 0:00:00 Installing collected packages: pip WARNING: The scripts pip, pip3 and pip3.10 are installed in '/home/gavannitsales/.local/bin' which is not on PATH. Consider adding this directory to PATH or, if you prefer to suppress this warning, use --no-warn-script-location. Successfully installed pip-23.1.2 gavannitsales@ubuntu22:~/sampleClone/hello-world$
requirements.txtにあるパッケージを入れる。
元のパッケージのtutorialフォルダのREADME.mdを読んでみたら同じフォルダにrequirements.txtがあるのでコピーして使わせてもらった。
gavannitsales@ubuntu22:~/sample/python-docs-samples/appengine/standard/flask/tutorial$ cat README.md :(中略) This sample shows how to use [Flask](http://flask.pocoo.org/) to handle requests, forms, templates, and static files on Google App Engine Standard. Before running or deploying this application, install the dependencies using [pip](http://pip.readthedocs.io/en/stable/): pip install -t lib -r requirements.txt For more information, see the [App Engine Standard README](../../README.md) gavannitsales@ubuntu22:~/sample/python-docs-samples/appengine/standard/flask/tutorial$ cat requirements.txt Flask==1.1.4; python_version < '3.0' Flask==2.1.0; python_version > '3.0' Werkzeug==1.0.1; python_version < '3.0' gavannitsales@ubuntu22:~/sample/python-docs-samples/appengine/standard/flask/tutorial$ cp -p requirements.txt ~/sampleClone/hello-world/ gavannitsales@ubuntu22:~/sampleClone/hello-world$ sudo pip install -r requirements.txt Ignoring Flask: markers 'python_version < "3.0"' don't match your environment Ignoring Werkzeug: markers 'python_version < "3.0"' don't match your environment Collecting Flask==2.1.0 Downloading Flask-2.1.0-py3-none-any.whl (95 kB) ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 95.2/95.2 KB 2.4 MB/s eta 0:00:00 Requirement already satisfied: click>=8.0 in /usr/lib/python3/dist-packages (from Flask==2.1.0->-r requirements.txt (line 2)) (8.0.3) Collecting Werkzeug>=2.0 Downloading Werkzeug-2.3.2-py3-none-any.whl (242 kB) ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 242.2/242.2 KB 7.9 MB/s eta 0:00:00 Collecting itsdangerous>=2.0 Downloading itsdangerous-2.1.2-py3-none-any.whl (15 kB) Requirement already satisfied: Jinja2>=3.0 in /usr/lib/python3/dist-packages (from Flask==2.1.0->-r requirements.txt (line 2)) (3.0.3) Collecting MarkupSafe>=2.1.1 Downloading MarkupSafe-2.1.2-cp310-cp310-manylinux_2_17_x86_64.manylinux2014_x86_64.whl (25 kB) Installing collected packages: MarkupSafe, itsdangerous, Werkzeug, Flask Attempting uninstall: MarkupSafe Found existing installation: MarkupSafe 2.0.1 Not uninstalling markupsafe at /usr/lib/python3/dist-packages, outside environment /usr Can't uninstall 'MarkupSafe'. No files were found to uninstall. Successfully installed Flask-2.1.0 MarkupSafe-2.1.2 Werkzeug-2.3.2 itsdangerous-2.1.2 WARNING: Running pip as the 'root' user can result in broken permissions and conflicting behaviour with the system package manager. It is recommended to use a virtual environment instead: https://pip.pypa.io/warnings/venv gavannitsales@ubuntu22:~/sampleClone/hello-world$
起動して、gceのvmホストが持ってる外部IPアドレスへブラウザで接続してみる。
gavannitsales@ubuntu22:~/sampleClone/hello-world$ sudo gunicorn -b 0.0.0.0:80 main:app [2023-04-28 23:38:44 +0000] [2345] [INFO] Starting gunicorn 20.1.0 [2023-04-28 23:38:44 +0000] [2345] [INFO] Listening at: http://0.0.0.0:80 (2345) [2023-04-28 23:38:44 +0000] [2345] [INFO] Using worker: sync [2023-04-28 23:38:44 +0000] [2346] [INFO] Booting worker with pid: 2346
はい見えた~。
見えたのはええけど、アプリでなんかタイムアウト起こしてる。
せやから最初の1回目のブラウザ表示遅いんやな。
今はpythonのアプリ動いたらええから放置。
docker入れる
次のステップでdocker使い始めるみたいやから、gceのvmにdokcer入れる。
gavannitsales@ubuntu22:~$ sudo apt-get install ca-certificates curl gnupg lsb-release Reading package lists... Done Building dependency tree... Done Reading state information... Done lsb-release is already the newest version (11.1.0ubuntu4). lsb-release set to manually installed. ca-certificates is already the newest version (20211016ubuntu0.22.04.1). ca-certificates set to manually installed. curl is already the newest version (7.81.0-1ubuntu1.10). curl set to manually installed. gnupg is already the newest version (2.2.27-3ubuntu2.1). gnupg set to manually installed. 0 upgraded, 0 newly installed, 0 to remove and 0 not upgraded. gavannitsales@ubuntu22:~$ gavannitsales@ubuntu22:~$ curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /usr/share/keyrings/docker-archive-keyring.gpg gavannitsales@ubuntu22:~$ echo \ "deb [arch=$(dpkg --print-architecture) signed-by=/usr/share/keyrings/docker-archive-keyring.gpg] https://download.docker.com/linux/ubuntu \ $(lsb_release -cs) stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null gavannitsales@ubuntu22:~$ sudo apt-get update Hit:1 http://us-central1.gce.archive.ubuntu.com/ubuntu jammy InRelease Get:2 http://us-central1.gce.archive.ubuntu.com/ubuntu jammy-updates InRelease [119 kB] Get:3 http://us-central1.gce.archive.ubuntu.com/ubuntu jammy-backports InRelease [108 kB] Get:4 https://download.docker.com/linux/ubuntu jammy InRelease [48.9 kB] Get:5 http://security.ubuntu.com/ubuntu jammy-security InRelease [110 kB] Get:6 https://download.docker.com/linux/ubuntu jammy/stable amd64 Packages [16.7 kB] Fetched 402 kB in 1s (554 kB/s) Reading package lists... Done gavannitsales@ubuntu22:~$ sudo apt-get install docker-ce :(中略) Setting up docker-ce (5:23.0.5-1~ubuntu.22.04~jammy) ... Created symlink /etc/systemd/system/multi-user.target.wants/docker.service → /lib/systemd/system/docker.service. Created symlink /etc/systemd/system/sockets.target.wants/docker.socket → /lib/systemd/system/docker.socket. Processing triggers for man-db (2.10.2-1) ... Processing triggers for libc-bin (2.35-0ubuntu3.1) ... Scanning processes... Scanning candidates... Scanning linux images... Running kernel seems to be up-to-date. Restarting services... Service restarts being deferred: systemctl restart networkd-dispatcher.service systemctl restart unattended-upgrades.service No containers need to be restarted. No user sessions are running outdated binaries. No VM guests are running outdated hypervisor (qemu) binaries on this host. gavannitsales@ubuntu22:~$
一般ユーザでdocker使うおまじないも入れて、いったんログアウトしてから再ログインする。
gavannitsales@ubuntu22:~$ sudo usermod -aG docker gavannitsales
追加できてるか確認し、hello-worldできるか確認。
あ、ここのhello-worldはpythonでローカルに作ったのとは別モノ。
gavannitsales@ubuntu22:~$ groups gavannitsales gavannitsales : gavannitsales adm dialout cdrom floppy audio dip video plugdev netdev lxd ubuntu google-sudoers docker gavannitsales@ubuntu22:~$ gavannitsales@ubuntu22:~$ sudo docker run hello-world Unable to find image 'hello-world:latest' locally latest: Pulling from library/hello-world 2db29710123e: Pull complete Digest: sha256:4e83453afed1b4fa1a3500525091dbfca6ce1e66903fd4c01ff015dbcb1ba33e Status: Downloaded newer image for hello-world:latest Hello from Docker! This message shows that your installation appears to be working correctly. To generate this message, Docker took the following steps: 1. The Docker client contacted the Docker daemon. 2. The Docker daemon pulled the "hello-world" image from the Docker Hub. (amd64) 3. The Docker daemon created a new container from that image which runs the executable that produces the output you are currently reading. 4. The Docker daemon streamed that output to the Docker client, which sent it to your terminal. To try something more ambitious, you can run an Ubuntu container with: $ docker run -it ubuntu bash Share images, automate workflows, and more with a free Docker ID: https://hub.docker.com/ For more examples and ideas, visit: https://docs.docker.com/get-started/ gavannitsales@ubuntu22:~$
インターネット経由でイメージ取得してエラーなしなのでOK。
コンテナ削除とイメージ削除できるかも確認。
gavannitsales@ubuntu22:~$ docker ps -a CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES 420dd58ee25f hello-world "/hello" About a minute ago Exited (0) About a minute ago distracted_bassi gavannitsales@ubuntu22:~$ docker rm 420dd58ee25f 420dd58ee25f gavannitsales@ubuntu22:~$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE hello-world latest feb5d9fea6a5 19 months ago 13.3kB gavannitsales@ubuntu22:~$ docker rmi feb5d9fea6a5 Untagged: hello-world:latest Untagged: hello-world@sha256:4e83453afed1b4fa1a3500525091dbfca6ce1e66903fd4c01ff015dbcb1ba33e Deleted: sha256:feb5d9fea6a5e9606aa995e879d862b825965ba48de054caab5ef356dc6b3412 Deleted: sha256:e07ee1baac5fae6a26f30cabfe54a36d3402f96afda318fe0a96cec4ca393359 gavannitsales@ubuntu22:~$
Dockerfile作る
サンプルフォルダの作成から。
cloud source repositoriesの登録で使ったフォルダをコピーする。
gavannitsales@ubuntu22:~$ cp -pR sampleClone/ GCRsample gavannitsales@ubuntu22:~$ cd GCRsample/hello-world gavannitsales@ubuntu22:~/GCRsample/hello-world$ ls README.md app.yaml main.py main_test.py requirements.txt gavannitsales@ubuntu22:~/GCRsample/hello-world$
同じフォルダにDockerfile作る。
vi Dockerfile FROM library/ubuntu:trusty LABEL description="Hello World Application" RUN apt-get update && \ apt-get -y install python gunicorn python-flask RUN mkdir /srv/hello-world COPY . /srv/hello-world WORKDIR /srv/hello-world EXPOSE 8000 ENTRYPOINT ["/usr/bin/gunicorn", "-b", ":8000", "main:app"]
ビルドする
ペーストしてるとわからんけど、dockerがバージョン23になってから、ビルドの画面の文字の流れ方変わったなぁ。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker build -t hello-world-container . [+] Building 35.8s (10/10) FINISHED => [internal] load build definition from Dockerfile 0.0s => => transferring dockerfile: 334B 0.0s => [internal] load .dockerignore 0.1s => => transferring context: 2B 0.0s => [internal] load metadata for docker.io/library/ubuntu:trusty 0.7s => [1/5] FROM docker.io/library/ubuntu:trusty@sha256:64483f3496c1373bfd55348e88694d1c4d0c9b660dee6bfef5 4.2s => => resolve docker.io/library/ubuntu:trusty@sha256:64483f3496c1373bfd55348e88694d1c4d0c9b660dee6bfef5 0.0s => => sha256:512123a864da5e2a62949e65b67106292c5c704eff90cac2b949fc8d7ac1e58e 189B / 189B 0.1s => => sha256:64483f3496c1373bfd55348e88694d1c4d0c9b660dee6bfef5e12f43b9933b30 1.20kB / 1.20kB 0.0s => => sha256:881afbae521c910f764f7187dbfbca3cc10c26f8bafa458c76dda009a901c29d 945B / 945B 0.0s => => sha256:13b66b487594a1f2b75396013bc05d29d9f527852d96c5577cc4f187559875d0 3.31kB / 3.31kB 0.0s => => sha256:2e6e20c8e2e69fa5c3fcc310f419975cef5fbeb6f7f2fe1374071141281b6a06 70.69MB / 70.69MB 0.9s => => sha256:0551a797c01db074ab0233ceb567e66b8ebdcb9de9a2e7baa36d57dfbca463a3 72.66kB / 72.66kB 0.1s => => extracting sha256:2e6e20c8e2e69fa5c3fcc310f419975cef5fbeb6f7f2fe1374071141281b6a06 2.8s => => extracting sha256:0551a797c01db074ab0233ceb567e66b8ebdcb9de9a2e7baa36d57dfbca463a3 0.0s => => extracting sha256:512123a864da5e2a62949e65b67106292c5c704eff90cac2b949fc8d7ac1e58e 0.0s => [internal] load build context 0.0s => => transferring context: 34.15kB 0.0s => [2/5] RUN apt-get update && apt-get -y install python gunicorn python-flask 29.9s => [3/5] RUN mkdir /srv/hello-world 0.4s => [4/5] COPY . /srv/hello-world 0.1s => [5/5] WORKDIR /srv/hello-world 0.0s => exporting to image 0.5s => => exporting layers 0.5s => => writing image sha256:5de507c26f8a19e551cf039c5805c670d0efc75a9ce373d8b64eca6502bc79fd 0.0s => => naming to docker.io/library/hello-world-container 0.0s gavannitsales@ubuntu22:~/GCRsample/hello-world$
コンテナ動くか確認
ビルドした結果使ってコンテナ動かす。
常用してるgcpのプロジェクトではcompose使ってるからdocker単体ではほぼ使わん。久しぶりにdocker runした。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker run -p 80:8000 hello-world-container 2023-04-29 21:05:05 [1] [INFO] Starting gunicorn 17.5 2023-04-29 21:05:05 [1] [INFO] Listening at: http://0.0.0.0:8000 (1) 2023-04-29 21:05:05 [1] [INFO] Using worker: sync 2023-04-29 21:05:05 [11] [INFO] Booting worker with pid: 11 2023-04-29 21:05:52 [1] [CRITICAL] WORKER TIMEOUT (pid:11) 2023-04-29 21:05:52 [1] [CRITICAL] WORKER TIMEOUT (pid:11) 2023-04-29 21:05:52 [14] [INFO] Booting worker with pid: 14
はい見えた。
GCR(Container Registory)への登録
次にGCRやってく。
参考にさせてもらったページ。作者さんありがとう。
このページ少し内容が古いからアレンジが必要。
さっき、ローカルで作ったdockerのイメージがあることを確認。
pythonでhello worldって表示するだけなんやけど245MBあって、けっこうデカいなぁ。ついでにdockerのバージョンは23を再確認。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE hello-world-container latest 5de507c26f8a 19 minutes ago 245MB gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker -v Docker version 23.0.5, build bc4487a gavannitsales@ubuntu22:~/GCRsample/hello-world$
これをGCRにpushしてく。
非推奨について(gcloud docker)
dockerのバージョン18.3以降はgcloud docker
がサポートされず。
非推奨の予告にあった。
pushしてくときの方法が参考にしたページとは変わってて、gcrに登録するために公式ページ参考にした。
同じようなことをしている方がいて、これも参考にさせてもらった。
作者さんありがとう。
こっからやってみる。
GCRのための認証(gcloud auth login)
gcpの認証しとく。
ブラウザで認証画面開けってあるから、認証コードをコピーして貼り付ける。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ gcloud auth login You are running on a Google Compute Engine virtual machine. It is recommended that you use service accounts for authentication. You can run: $ gcloud config set account `ACCOUNT` to switch accounts if necessary. Your credentials may be visible to others with access to this virtual machine. Are you sure you want to authenticate with your personal account? Do you want to continue (Y/n)? Y Go to the following link in your browser: https://accounts.google.com/o/oauth2/auth?response_type=code&client_id=32555940559.apps.googleusercontent.com&redirect_uri=https%3A%2F%2Fsdk.cloud.google.com%2Fauthcode.html&scope=openid+https%3A%2F%2Fwww.googleapis.com%2Fauth%2Fuserinfo.email+https%3A%2F%2Fwww.googleapis.com%2Fauth%2Fcloud-platform+https%3A%2F%2Fwww.googleapis.com%2Fauth%2Fappengine.admin+https%3A%2F%2Fwww.googleapis.com%2Fauth%2Fsqlservice.login+https%3A%2F%2Fwww.googleapis.com%2Fauth%2Fcompute+https%3A%2F%2Fwww.googleapis.com%2Fauth%2Faccounts.reauth&state=5kI8tuy5M5tkgodbf44G5EXt6DSVcN&prompt=consent&access_type=offline&code_challenge=n1FnysifOhZJ4q1NT1koimVlQ9q0ig3wDP5qlpXFRqk&code_challenge_method=S256 Enter authorization code: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx You are now logged in as [gavannitsales@gmail.com]. Your current project is [fourth-elixir-383118]. You can change this setting by running: $ gcloud config set project PROJECT_ID gavannitsales@ubuntu22:~/GCRsample/hello-world$
docker認証ヘルパーに登録(gcloud auth configure-docker)
gcloudをdocker認証ヘルパーに登録しとく。
再実行したいときは、jsonファイル削除しておいてもええ。
削除しとかない場合はwarning出るけど無視しといてもええ。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ gcloud auth configure-docker Adding credentials for all GCR repositories. WARNING: A long list of credential helpers may cause delays running 'docker build'. We recommend passing the registry name to configure only the registry you are using. After update, the following will be written to your Docker config file located at [/home/gavannitsales/.docker/config.json]: { "credHelpers": { "gcr.io": "gcloud", "us.gcr.io": "gcloud", "eu.gcr.io": "gcloud", "asia.gcr.io": "gcloud", "staging-k8s.gcr.io": "gcloud", "marketplace.gcr.io": "gcloud" } } Do you want to continue (Y/n)? Docker configuration file updated. gavannitsales@ubuntu22:~/GCRsample/hello-world$ ls -l /home/gavannitsales/.docker total 8 drwx------ 5 gavannitsales gavannitsales 4096 Apr 29 20:53 buildx -rw------- 1 gavannitsales gavannitsales 204 Apr 29 21:28 config.json gavannitsales@ubuntu22:~/GCRsample/hello-world$
ローカルイメージにタグ付けする。
今はv1.0とかつけとく。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker tag hello-world-container gcr.io/fourth-elixir-383118/hello-world-container:v1.0 gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE hello-world-container latest 5de507c26f8a 2 hours ago 245MB gcr.io/fourth-elixir-383118/hello-world-container v1.0 5de507c26f8a 2 hours ago 245MB gavannitsales@ubuntu22:~/GCRsample/hello-world$
GCRに登録(docker push)
次にpushしてgcrに登録する。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ docker push gcr.io/fourth-elixir-383118/hello-world-container:v1.0 The push refers to repository [gcr.io/fourth-elixir-383118/hello-world-container] 5f70bf18a086: Pushed 76587561c5b7: Pushed 16c5158656f7: Pushed fdbd8112be4a: Pushed 83109fa660b2: Layer already exists 30d3c4334a23: Layer already exists f2fa9f4cf8fd: Layer already exists v1.0: digest: sha256:fe215a34dc5b5ea4cc1f22c809798e507562daaf9085e1a8304d91d515758554 size: 1779 gavannitsales@ubuntu22:~/GCRsample/hello-world$
ここまで行けたら登録結果が見える。
おお、行けたやん。
GCRに登録するとバケットがcloud storageに自動で作られる。
docker images
ってやったときに見える内容に似てる。
ローカルのimagesからいったん作ったイメージを削除し、さっきpushしたイメージをpullして動かしてみる。
gavannitsales@ubuntu22:~/hoge$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE hello-world-container latest 5de507c26f8a 2 hours ago 245MB gcr.io/fourth-elixir-383118/hello-world-container v1.0 5de507c26f8a 2 hours ago 245MB gavannitsales@ubuntu22:~/hoge$ docker rmi gcr.io/fourth-elixir-383118/hello-world-container:v1.0 Untagged: gcr.io/fourth-elixir-383118/hello-world-container:v1.0 Untagged: gcr.io/fourth-elixir-383118/hello-world-container@sha256:fe215a34dc5b5ea4cc1f22c809798e507562daaf9085e1a8304d91d515758554 gavannitsales@ubuntu22:~/hoge$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE hello-world-container latest 5de507c26f8a 2 hours ago 245MB gavannitsales@ubuntu22:~/hoge$ gavannitsales@ubuntu22:~/hoge$ gavannitsales@ubuntu22:~/hoge$ docker pull gcr.io/fourth-elixir-383118/hello-world-container:v1.0 v1.0: Pulling from fourth-elixir-383118/hello-world-container Digest: sha256:fe215a34dc5b5ea4cc1f22c809798e507562daaf9085e1a8304d91d515758554 Status: Downloaded newer image for gcr.io/fourth-elixir-383118/hello-world-container:v1.0 gcr.io/fourth-elixir-383118/hello-world-container:v1.0 gavannitsales@ubuntu22:~/hoge$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE hello-world-container latest 5de507c26f8a 2 hours ago 245MB gcr.io/fourth-elixir-383118/hello-world-container v1.0 5de507c26f8a 2 hours ago 245MB gavannitsales@ubuntu22:~/hoge$ gavannitsales@ubuntu22:~/hoge$ docker run -p 80:8000 gcr.io/fourth-elixir-383118/hello-world-container:v1.0 2023-04-29 22:52:54 [1] [INFO] Starting gunicorn 17.5 2023-04-29 22:52:54 [1] [INFO] Listening at: http://0.0.0.0:8000 (1) 2023-04-29 22:52:54 [1] [INFO] Using worker: sync 2023-04-29 22:52:54 [11] [INFO] Booting worker with pid: 11
同じようにブラウザで表示できた。
GKEで動かす
GCRに登録したアプリをGKEで動かしてみる。
クラスタ作成甘くない
まずはクラスタ作成して接続。
gavannitsales@ubuntu22:~/gcloud$ gcloud config set project fourth-elixir-383118 Updated property [core/project]. gavannitsales@ubuntu22:~/gcloud$ gavannitsales@ubuntu22:~/gcloud$ gcloud config set compute/zone us-central1-c Updated property [compute/zone]. gavannitsales@ubuntu22:~/gcloud$ gavannitsales@ubuntu22:~/gcloud$ gcloud container clusters create nariCluster --num-nodes=3 Default change: VPC-native is the default mode during cluster creation for versions greater than 1.21.0-gke.1500. To create advanced routes based clusters, please pass the `--no-enable-ip-alias` flag Default change: During creation of nodepools or autoscaling configuration changes for cluster versions greater than 1.24.1-gke.800 a default location policy is applied. For Spot and PVM it defaults to ANY, and for all other VM kinds a BALANCED policy is used. To change the default values use the `--location-policy` flag. Note: Your Pod address range (`--cluster-ipv4-cidr`) can accommodate at most 1008 node(s). Creating cluster hello-world in us-central1-c... Cluster is being deployed...⠛
なんでか知らんけど、クラスタ作ったときにwarning出てgoogle-cloud-sdk-gke-gcloud-auth-plugin
あらへんって怒られたからインストールしようとした。
# apt-get update && apt-get install google-cloud-cli-gke-gcloud-auth-plugin … Reading package lists... Done Building dependency tree Reading state information... Done E: Unable to locate package google-cloud-cli-gke-gcloud-auth-plugin
同じようなこと悩んでるときの対処方法がgithubにあった。
apt-getの参照先追加したらええみたいやったから、対処してみた。
root@ubuntu22:~# apt-get update Hit:1 http://us-central1.gce.archive.ubuntu.com/ubuntu jammy InRelease Hit:2 http://us-central1.gce.archive.ubuntu.com/ubuntu jammy-updates InRelease Hit:3 http://us-central1.gce.archive.ubuntu.com/ubuntu jammy-backports InRelease Hit:5 https://download.docker.com/linux/ubuntu jammy InRelease Hit:4 https://packages.cloud.google.com/apt kubernetes-xenial InRelease Get:6 http://security.ubuntu.com/ubuntu jammy-security InRelease [110 kB] Fetched 110 kB in 1s (135 kB/s) Reading package lists... Done W: https://apt.kubernetes.io/dists/kubernetes-xenial/InRelease: Key is stored in legacy trusted.gpg keyring (/etc/apt/trusted.gpg), see the DEPRECATION section in apt-key(8) for details. root@ubuntu22:~# root@ubuntu22:~# root@ubuntu22:~# cat /etc/apt/sources.list.d/ docker.list kubernetes.list root@ubuntu22:~# cat /etc/apt/sources.list.d/kubernetes.list deb https://apt.kubernetes.io/ kubernetes-xenial main root@ubuntu22:~# echo "deb [signed-by=/usr/share/keyrings/cloud.google.gpg] https://packages.cloud.google.com/apt cloud-sdk main" | sudo tee -a /etc/apt/sources.list.d/google-cloud-sdk.list deb [signed-by=/usr/share/keyrings/cloud.google.gpg] https://packages.cloud.google.com/apt cloud-sdk main root@ubuntu22:~# cat /etc/apt/sources.list.d/kubernetes.list deb https://apt.kubernetes.io/ kubernetes-xenial main root@ubuntu22:~# curl https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key --keyring /usr/share/keyrings/cloud.google.gpg add - % Total % Received % Xferd Average Speed Time Time Time Current Dload Upload Total Spent Left Speed 0 0 0 0 0 0 0 0 --:--:-- --:--:-- --:--:-- 0Warning: apt-key is deprecated. Manage keyring files in trusted.gpg.d instead (see apt-key(8)). 100 1210 100 1210 0 0 8948 0 --:--:-- --:--:-- --:--:-- 8962 OK root@ubuntu22:~# root@ubuntu22:~# sudo apt-get install google-cloud-sdk-gke-gcloud-auth-plugin Reading package lists... Done Building dependency tree... Done Reading state information... Done The following NEW packages will be installed: google-cloud-sdk-gke-gcloud-auth-plugin 0 upgraded, 1 newly installed, 0 to remove and 0 not upgraded. Need to get 3129 kB of archives. After this operation, 11.0 MB of additional disk space will be used. Get:1 https://packages.cloud.google.com/apt cloud-sdk/main amd64 google-cloud-sdk-gke-gcloud-auth-plugin amd64 428.0.0-0 [3129 kB] Fetched 3129 kB in 0s (17.5 MB/s) Selecting previously unselected package google-cloud-sdk-gke-gcloud-auth-plugin. (Reading database ... 101371 files and directories currently installed.) Preparing to unpack .../google-cloud-sdk-gke-gcloud-auth-plugin_428.0.0-0_amd64.deb ... Unpacking google-cloud-sdk-gke-gcloud-auth-plugin (428.0.0-0) ... Setting up google-cloud-sdk-gke-gcloud-auth-plugin (428.0.0-0) ... Scanning processes... Scanning linux images... Running kernel seems to be up-to-date. No services need to be restarted. No containers need to be restarted. No user sessions are running outdated binaries. No VM guests are running outdated hypervisor (qemu) binaries on this host. root@ubuntu22:~#
クラスタ作成やりなおし
気を取り直してクラスタ作りなおし。
何回も打鍵めんどうやから、.shに書いた。
クラスタは作るのに5分ぐらい待つ。
Pod起動がうまく行って検証するまで3回ぐらいクラスタ作り直した。
gavannitsales@ubuntu22:~$ cat connectGcloud.sh gcloud config set project fourth-elixir-383118 gcloud config set compute/zone us-central1-a gcloud projects describe fourth-elixir-383118 gavannitsales@ubuntu22:~$ gavannitsales@ubuntu22:~$ sh ./connectGcloud.sh Updated property [core/project]. Updated property [compute/zone]. createTime: '2023-04-08T18:24:56.947Z' lifecycleState: ACTIVE name: gvis-7502 projectId: fourth-elixir-383118 projectNumber: '225919338029' gavannitsales@ubuntu22:~$ gavannitsales@ubuntu22:~$ cat makeGke.sh gcloud container clusters create narigke --num-nodes=3 gavannitsales@ubuntu22:~$ sh ./makeGke.sh Default change: VPC-native is the default mode during cluster creation for versions greater than 1.21.0-gke.1500. To create advanced routes based clusters, please pass the `--no-enable-ip-alias` flag Default change: During creation of nodepools or autoscaling configuration changes for cluster versions greater than 1.24.1-gke.800 a default location policy is applied. For Spot and PVM it defaults to ANY, and for all other VM kinds a BALANCED policy is used. To change the default values use the `--location-policy` flag. Note: Your Pod address range (`--cluster-ipv4-cidr`) can accommodate at most 1008 node(s). Creating cluster narigke in us-central1-a... Cluster is being health-checked (master is healthy)...done. Created. To inspect the contents of your cluster, go to: https://console.cloud.google.com/kubernetes/workload_/gcloud/us-central1-a/narigke?project=fourth-elixir-383118 kubeconfig entry generated for narigke. NAME LOCATION MASTER_VERSION MASTER_IP MACHINE_TYPE NODE_VERSION NUM_NODES STATUS narigke us-central1-a 1.25.7-gke.1000 34.71.84.23 e2-medium 1.25.7-gke.1000 3 RUNNING gavannitsales@ubuntu22:~$https://container.googleapis.com/v1/projects/fourth-elixir-383118/zones/us-central1-a/clusters/narigke
クラスタの認証情報取得して接続
認証情報取得して、作ったクラスタに接続する。
gavannitsales@ubuntu22:~$ gcloud container clusters get-credentials narigke Fetching cluster endpoint and auth data. kubeconfig entry generated for narigke. gavannitsales@ubuntu22:~$
Pod起動
Podを起動する。
クラスタ作ってすぐ実行したらcouldn't get resource list for metrics.k8s.io/v1beta1: the server is currently unable to handle the request
って表示されることあるけど起動はできる。
gavannitsales@ubuntu22:~$ kubectl run hello-world --image=gcr.io/fourth-elixir-383118/hello-world-container:v1.0 --port=8000 pod/hello-world created gavannitsales@ubuntu22:~$ kubectl get pod NAME READY STATUS RESTARTS AGE hello-world 1/1 Running 0 10m gavannitsales@ubuntu22:~$
GKEでワークロード画面確認すると、起動した。
外部接続のためにロードバランス
Pod起動の次はservice作成して外部接続できるようにする。
コンテナのポート8000を、ポート80で公開する。LoadBalancer Ingress
って書いてあるIPアドレスをブラウザで開いてみる。
gavannitsales@ubuntu22:~/GCRsample/hello-world$ kubectl expose pod/hello-world --port=80 --target-port=8000 --type=LoadBalancer service/hello-world exposed gavannitsales@ubuntu22:~/GCRsample/hello-world$ kubectl describe service/hello-world Name: hello-world Namespace: default Labels: run=hello-world Annotations: cloud.google.com/neg: {"ingress":true} Selector: run=hello-world Type: LoadBalancer IP Family Policy: SingleStack IP Families: IPv4 IP: 10.112.5.155 IPs: 10.112.5.155 LoadBalancer Ingress: 35.232.237.56 Port: <unset> 80/TCP TargetPort: 8000/TCP NodePort: <unset> 30641/TCP Endpoints: 10.108.2.8:8000 Session Affinity: None External Traffic Policy: Cluster Events: Type Reason Age From Message ---- ------ ---- ---- ------- Normal EnsuringLoadBalancer 19s service-controller Ensuring load balancer gavannitsales@ubuntu22:~/GCRsample/hello-world$
サービス公開できた。
エンドポイントってあるところをブラウザで開いてみる。
はい、表示できた。
ログの見え方
ポッドのログ見ると「イベント」ってところにコンテナとかロードバランサの作成・削除が見える。
何度か作り直すとわかるんやけど、外部接続するIPアドレスはコロコロ変わる。
ローカルで動かしたときに見えたログはPodのログ画面で見える。
ログはjson形式で冗長な上、表示遅い。
内容がcriticalのものはええけど、infoのものでも左端の赤い表示になるのは気に入らんなぁ。
